MOLYKOTE D-321R AN-FR

Main features

Room-Temperature Application Cure
Dry Film Lubricant Formulation
180 to 450 deg C Service Range

Product Description

MOLYKOTE® D-321 R Anti-Friction Coating is an air-curing dry-film lubricant supplied as a bulk liquid or aerosolized spray. Its solid-lubricant and binder system forms a gray-black lubricating film for high-load metal-to-metal interfaces operating with slow to medium-speed movement. The coating supports running-in and boundary-lubrication requirements while helping avoid stick-slip. A recommended dry-film thickness of 5 to 20 µm and a documented service temperature range of -180 to 450°C support evaluation across demanding mechanical assemblies and extreme-temperature environments.

Key features

Air-curing dry-film lubrication: Becomes touch-dry after 5 minutes at 23°C and is fully cured and ready for use after 2 hours at 23°C.
High-load metal interface performance: Formulated for metal-to-metal combinations with slow to medium-speed movement and high loads.
Broad service temperature range: The applied coating has a documented service temperature range of -180 to 450°C.

Applications / Suitable for

Plain bearings, bushings and sleeves
Power screw drives
Threaded connections and fasteners
Slides, guides and tracks
High-voltage switches, including operation under high vacuum and extreme temperatures

TDS, SDS & Technical Documents

Technical Specifications

General Properties

Color

gray-black

Density

1070 kg/m3

Thermal Properties

Operating Temperature

-180 - 450 °C

Additional Information

Technical properties

As-supplied / before-processing properties

Typical values for the bulk liquid coating. These values are not intended for use as specification limits.

Property	Value	Unit	Method / condition
Color	Gray-black	—	Typical
Viscosity	23	seconds	ISO 2431; 23°C; #3 cup
Density	1.07	g/ml	DIN 53217/2; 20°C
Nonvolatile content	29	%	CTM 0242 I
