LOCTITE NCI 7002 E&C
Harmonization Code : 32159090 | Printing ink, writing or drawing ink, and other inks, whether or not concentrated or solid, specifically for those classified as other within that category
Main features
- Non-Conductive
- Screen Printable
- Flexible low temperature drying cycles
Product Description
LOCTITE NCI 7002 E&C is a screen printable ink that is specifically designed for blending with LOCTITE ECI 7004HR E&C and LOCTITE ECI 7004LR E&C printable ink to provide a range of resistance values.
LOCTITE NCI 7002 E&C is often used to print force sensitivity resistors, heating elements, and printed resistors onto polyester foil. It presents a technologically advanced solution in the realm of conductive inks, boasting a thermoplastic composition characterized by its striking black appearance. Leveraging a heat cure mechanism, this product demonstrates exceptional performance even under elevated temperatures, with a maximum operating temperature of 100ºC.
Delivering a host of product benefits, LOCTITE NCI 7002 E&C stands out as a non-conductive ink renowned for its versatility and reliability. Its screen printable nature facilitates seamless application onto various substrates, while its flexible resistive properties ensure optimal functionality across a spectrum of demanding applications. Additionally, this ink offers excellent screen residence time, coupled with flexible low temperature drying cycles, enhancing both efficiency and convenience during assembly processes. With its commendable adhesion capabilities, LOCTITE NCI 7002 E&C excels in providing robust protection against electrostatic discharge (ESD), making it an indispensable choice for printed resistors, sensing devices, heating elements, and more.
LOCTITE NCI7002
Unlike other products we offer, the products listed on this page cannot currently be ordered directly from the website.
Shipping in 12 weeks
Shipping in 12 weeks
Shipping in 30 daysTDS, SDS & Technical Documents
Technical Specifications
General Properties
Physical Properties
Additional Information
Blends of LOCTITE NCI 7002 E&C and LOCTITE ECI 7004HR E&C and LOCTITE ECI 7004LR E&C can be dried in conventional air circulated ovens. Higher temperatures will shorten the drying time and will lead to more stable resistance values.
For high speed production, jet drying, infra-red drying and drying in high speed reel-to-reel equipment can be used. The above cure profile is a guideline recommendation. Cure conditions (time and temperature) may vary based on customers' experience and their application requirements, as well as customer curing equipment, oven loading and actual oven temperatures.
