CONATHANE EN-1554

Main features

Polyether-Based Polyurethane for Harness Breakouts
550% Cured Elongation
Water and Fuel Resistance

Product Description

CONATHANE® EN-1554 Polyurethane Encapsulant is a two-component polyether-based polyurethane system for molding, encapsulating, and potting harness breakouts, watertight connectors, cables, cable-end seals, printed circuitry, and other electrical components. The black or amber system uses a 100:33 mix ratio by weight and may be cured at room or elevated temperature. After cure, it forms a tough, cold-flow-resistant elastomer with documented resistance to oils, gasoline, JP-4 fuel, water, and seawater. Typical cured properties include Shore A 85 hardness, 550% elongation, and 600 V/mil dielectric strength.

Key features

Cable and connector encapsulation: The polyurethane system is documented for harness breakouts, watertight connectors, cables, and cable-end seals.
Tough flexible elastomer: Typical cured data include Shore A 85 hardness and 550% elongation.
Fluid and moisture resistance: The cured material is documented for oils, gasoline, JP-4 fuel, water, and seawater.

Applications / Suitable for

Harness breakouts and watertight connectors
Cables and cable-end seals
Printed circuitry and electrical components

TDS, SDS & Technical Documents

Technical Specifications

No specifications available.

Additional Information

Technical properties

As-supplied / before-processing properties

Typical as-supplied or processing-state values unless otherwise stated. These values are not sales specifications.

Property	Value	Unit	Method / condition
Product form	Two-component polyurethane	N/A	System
Color	Black or amber	N/A	Available configurations
Mix ratio	100:33	parts by weight	Part A : Part B
Mix ratio	3:1	parts by volume	Part A : Part B
Cure option	16	h	At 82.2°C
Cure option	10 to 12	h	At 100°C
